HPE Aruba JL075A — Aruba 3810M 16SFP+ 2-Slot Switch

What it is

JL075A is an HPE Aruba 3810M Series enterprise switch that combines high-density 10 GbE fiber connectivity with modular uplink flexibility.
It provides 16 × 10 GbE SFP+ fiber ports and 2 modular expansion slots for additional uplinks or stacking modules, making it a strong choice for aggregation, distribution, and spine/access roles in campus and branch networks.

Why buyers pick JL075A (plain English)

High-density 10 Gb fiber access
Sixteen 10 GbE SFP+ ports deliver robust bandwidth for servers, uplinks, and fiber backbones.

Modular uplink flexibility
Two expansion slots support optional modules — such as high-speed uplinks, stacking modules, or additional port types — so you can tailor the switch to your network design.

Enterprise-grade performance
Delivers resilient switching, rich QoS, and advanced security features built for campus and distribution environments.

Aruba OS-CX / AOS support
Integrates with Aruba’s modern network OS for reliable management, automation, and policy enforcement.

Scalable and stack-ready
Supports optional stacking modules to operate multiple switches as a single logical unit for simplified management and resiliency.

60-second spec box (JL075A)

Switch type
Enterprise aggregation / distribution switch

Ports
16 × 10 GbE SFP+ fiber

Expansion slots
2 × modular expansion (uplinks/stacking)

Operating system
Aruba OS-CX / AOS

Form factor
1U rack-mount

Stacking
Optional stacking via modules

Use case
Campus aggregation, distribution, server uplinks, fiber-centric access.

Where it fits (and when to choose something else)

Perfect for:

  • Fiber-forward aggregation and distribution layers

  • Server farms needing 10 Gb connectivity

  • Networks that may grow or change over time

  • Deployments needing modular uplinks or stacking

Choose something else if:

  • You need PoE access → Aruba 6200/6300 Series

  • You want a fixed port count without expansion → Aruba 8320/8400 fixed models

  • You need higher speeds (25/40/100 Gb) → Aruba 8400 modular with appropriate line cards

TL;DR

JL075A is Aruba’s 3810M 16SFP+ modular switch with two expansion slots:
a high-density fiber access and modular uplink platform for campus aggregation and distribution networks.

Product Description Aruba 3810M 16SFP+ 2-slot Switch - switch - 16 ports - managed - rack-mountable
Device Type Switch - 16 ports - L3 - managed - stackable
Enclosure Type Rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 16 x 10 Gigabit SFP+
Performance Latency (1 Gbps): 2.8 µs ¦ Latency (10 Gbps): 1.8 µs ¦ Latency (40 Gbps): 1.5 µs ¦ Throughput (64-byte packet size): up to 285.7 Mpps ¦ Routing/switching capacity: 480 Gbps ¦ Switching fabric speed: 508 Gbps
Capacity IPv4 routing table entries: 10000 ¦ IPv6 forwarding table entries: 5000
MAC Address Table Size 64K entries
Jumbo Frame Support Yes
Routing Protocol OSPF, BGP-4, RIP-1, RIP-2, BGP, VRRP, OSPFv2, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, Bidirectional Forwarding Detection (BFD), CIDR
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, CLI, XRMON, SSH 6
Features Flow control, DHCP support, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, IPv6 support, half duplex mode, full duplex mode, sFlow, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), Per-VLAN Spanning Tree Plus (PVST+), STP Root Guard, Uni-Directional Link Detection (UDLD), Link Aggregation Control Protocol (LACP), dynamic ARP protection, DHCP protection, Dynamic VLAN Support (GVRP), Zero Touch Auto Provisioning, Multiple VLAN Registration Protocol (MVRP), Ingress Layer 2 MAC Access Control Lists (ACLs), Class of Service (CoS), MACsec support, DNS client, layer 4 prioritization, 13.5MB packet buffer
Compliant Standards IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1AX
Power Redundancy Yes
Dimensions (WxDxH) 17.4 in x 17 in x 1.7 in
Weight 13.27 lbs
General Information
Device Type Switch - 16 ports - L3 - managed - stackable
Enclosure Type Rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 16 x 10 Gigabit SFP+
Performance
  • Latency (1 Gbps): 2.8 µs
  • Latency (10 Gbps): 1.8 µs
  • Latency (40 Gbps): 1.5 µs
  • Throughput (64-byte packet size): up to 285.7 Mpps
  • Routing/switching capacity: 480 Gbps
  • Switching fabric speed: 508 Gbps
Capacity
  • IPv4 routing table entries: 10000
  • IPv6 forwarding table entries: 5000
MAC Address Table Size 64K entries
Jumbo Frame Support Yes
Routing Protocol OSPF, BGP-4, RIP-1, RIP-2, BGP, VRRP, OSPFv2, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, Bidirectional Forwarding Detection (BFD), CIDR
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, CLI, XRMON, SSH 6
Encryption Algorithm MD5, SSL, TLS
Authentication Method RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP)
Features Flow control, DHCP support, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, IPv6 support, half duplex mode, full duplex mode, sFlow, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), Per-VLAN Spanning Tree Plus (PVST+), STP Root Guard, Uni-Directional Link Detection (UDLD), Link Aggregation Control Protocol (LACP), dynamic ARP protection, DHCP protection, Dynamic VLAN Support (GVRP), Zero Touch Auto Provisioning, Multiple VLAN Registration Protocol (MVRP), Ingress Layer 2 MAC Access Control Lists (ACLs), Class of Service (CoS), MACsec support, DNS client, layer 4 prioritization, 13.5MB packet buffer
Compliant Standards IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1AX
Processor 2
RAM 6 GB DDR3 SDRAM
Flash Memory 1 GB
Expansion / Connectivity
Interfaces
  • 16 x 10Gbit LAN SFP+
  • 1 x serial (console) RJ-45
  • 1 x management RJ-45
  • 1 x RJ-45
  • 1 x micro-USB Type B
Expansion Slots
  • 1 (total) / 1 (free) x Stacking Module slot
  • 2 (total) / 2 (free) x expansion slot
Power
Power Device Internal power supply - hot-plug
Installed Qty 0 (installed) / 2 (max)
Power Redundancy Yes
Miscellaneous
Included Accessories Fan tray
Rack Mounting Kit Included
Compliant Standards FCC Class A certified, CISPR 22 Class A, EN 60950, EN55022, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 60950, UL 60950, Laser Class 1, UL 60950-1, EN 60825, CAN/CSA C22.2 No. 60950-1, EN 61000-3-3:2008, CAN/CSA C22.2 No. 60950, VCCI Class A, EN55022:2010, EN55024:2010, IEC 60950-1:2005 Second Edition, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 62368-1 Second Edition, IEC 60825:2007, EN 60850-1:2007, IEC 60825-1:2007 Class 1, UL 62368-1 Second Edition
Dimensions & Weight
  • Width: 17.4 in
  • Depth: 17 in
  • Height: 1.7 in
  • Weight: 13.27 lbs
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 113 °F
Humidity Range Operating 15 - 95% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F
Humidity Range Storage 15 - 90% (non-condensing)
